FD22 facial recognition video intercom module, as a comprehensive upgrade of FD21, not only inherits the outstanding advantages of FD21 in recognition technology and hardware quality, but also integrates the video intercom function in a breakthrough way, aiming to create an innovative solution for users that integrates identity recognition and instant communication. It is widely used in smart buildings, smart communities, high-end security and other fields.
Features:
Accurate dual identification: Integrates 3D face recognition and palm vein recognition to resist photo/video fraud and ensure safety.
Real-time video intercom: Supports real-time viewing of visitor images and two-way voice calls to improve the convenience of interaction.
Industrial-grade performance: Equipped with a high-performance main control chip, it has fast processing, stable transmission, and clear images.
Rugged and easy to use: Anti-vibration and anti-fall, adaptable to complex environments, lightweight, easy to install and operate.
Technical Parameters:
| Project | Technical Parameters |
| Module Size | 40×20mm |
| Operating Voltage | 5.0V–9.0V |
| Operating Current | 300–335mA |
| Power-On Time | <0.34s |
| Interface | - UART: 4-pin, 3.3V TTL, 115200bps
- USB 2.0: 5-pin, UVC protocol |
| RGB Lens | - Resolution: 1/6.5", 1280H×960V
- Field of View (FoV):
- Horizontal (H): 60.4°
- Vertical (V): 47.6°
- Diagonal (D): 72.6° |
| IR Lens | - Resolution: 1/6.5", 1280H×960V
- Field of View (FoV):
- Horizontal (H): 60.4°
- Vertical (V): 47.6°
- Diagonal (D): 72.6° |
| Face Recognition | - User Capacity: 100
- Registration Distance: 875px~2500px
- Matching Distance: 1000px~2500px
- False Rejection Rate (FRR): <0.1%
- False Acceptance Rate (FAR): <0.001%
- 1:N Search Time: <1s |
| Palm Vein Recognition | - User Capacity: 100
- Registration Distance: 500px~750px
- Matching Distance: 500px~750px
- False Rejection Rate (FRR): <0.1%
- False Acceptance Rate (FAR): <0.001%
- 1:N Search Time: <1s |
| Environment and Reliability | - Storage Temperature: -40℃～85℃
- Operating Temperature: -30℃～70℃
- Operating Humidity: <93% (No Condensation)
- Electrostatic Discharge (ESD HBM): ±2000V |
Details:
Applications:
Smart building security: empower office buildings/commercial complexes, support face recognition access, video intercom and elevator linkage call, improve management efficiency and safety.
Smart community access management: used for community gates/unit buildings, residents can quickly pass through by face recognition, visitors can have video intercom, and the property can monitor access control records in real time.
High-end smart home: integrated into smart door locks, supports video intercom between indoor terminals and visitors, and remotely controls home security.
